KAIYUAN 5E-IRSII Infrared Sulfur Analyzer

This instrument is used to determine the sulfur content in coal, coke and oil products, and applied in the thermal power stations, coal mines, etc. The instrument is equipped with infrared cell to detect the SO2 gas produced by burning the sample which is consequently used to determine the total sulfur content. It has a thermocouple off protection, over temperature alarming protection and auto-diagnostic. A visible program under windows to display all the analysis process is available. Specification: Sulfur resolution: 0.001% Sulfur range: 0.01-10% Analysis time per test: + / - 100 secs Furnace temperature control: 900-1350 C Oven temperature precision: 48C + / - 1C Temperature resolution: 1C Sample mass: Coal: 300mg; Oil: 80-120mg Standard test method: ASTM D4239 Power: 5 kW
